MODEL:KRD

AUTO RESIN FINISHING DISPENSING SYSTEM

Benefits

  1. Increase accuracy：
    Computer controlled and connect the load-cell. It can reach the required accuracy .
  2. Eliminate mistake,improve quality：
    Operator no need to calculate the recipe,make-up solution.Maintains hifh production quality standards .
  3. Cost saving：
    Economical chemical usage by elimination of waste.10% saving are expected.
  4. Efficency：
    Can using air membraned pump to deliver the chemicals to doing unit.It makes simple engineering plant.
  5. Environment approve：
    Compact design and limited space occuqied.The system can brings the environment cleaning and safety.
  6. Management report：
    Provide daily and monthly consumption static report.Detailed weighing record can be a part of procedure management.

Specifications

Structure

No. of chemical
Up to 30
Disoensung valve
Pneumatic valve(Meterial PVC or SUS304)
Chenical supply
Air diaphragm pump or high position storage tank
Control method
By PLC / HMI and IPC
Solution supply
SUS304 Rack with compacted plastic board
Material
Stainless steel frame with impacted PVC board.
Computer for recipe station
IBM Compatible(prepare by customer)
Software

Auto mack-up,consumptiom report,network operation.
Utility Water:1,1/2"、Power380V,3P,50/60Hz,、Air:5kg/c㎡
Dimension/Weights

1T:965mm(L)×1200mm(D)×1580mm(H),300kg appro
3T:1170mm(L)×1090mm(D)×1870mm(H),400kg appro

krd02
(Specifications are subject to change without notice)

Features

krd04
krd05
krd06
krd04
  1. Eliminate the writing and calculation errors by human.
  2. Digitalize display of make-up process.
  3. Using a pair of load-cell can control with weighing accuracy.
  4. Clean the tube automatically after disoensing.
  5. Provide the weighing report as well as consumption.
  6. Recipe dinpensing completely and transport to service tank automatically.
  7. Can provide up to 4 stenters(Model:KRD-3T).
  8. Can install a PLC controller beisde each stenter.(Option)
krd07
krd08
krd09
krd10
fb1
krd03

1T

3T
