MODEL:mSLD

AUTO LIQUID DISPENSING SYSTEM
(FOR SMALL QUANTITY)

ELIMINATE HUMAN ERROR
IMPROVE EFFICIENCY

FEATURES:

• Improve the accuracy of small quantity chemical weighing.

• Eliminate human error,product quality up

• Less chemical waste,cost saving.

• Cleaning the individual tube after dispensing.

• Provide detail weighing record and consumption report.

SPECIFICATIONS:

AUTO LIDUID DISPENSING SYSTEM
(FOR SMALL QUANTITY)

No. of chemical	Max 36, divide into 6 area.
Dispensing Valve	Solenoid diaphragm valve.
Chemical Supply	Air diaphragm pump or gravitate.(Only diaphragm pump if high viscosity chemical)
Control	PLC
Frame	SUS304 rack,with impacted PVC board for upper.SUS304 for lower.
Computer	IBM compatible PC
Utility	Water:1",Power:220V,50/60Hz,10A,single phase Air compressor:5kg/c㎡
Dimensions & Weight	67cm(W)×58cm(D)×173cm(H),140kg appro
